MATRUSREE has the complete line of configurable Electric Duct Heaters that are perfectly suited to your HVAC applications, provided with Long Life Heating Elements specially designed for HVAC Environment using highest Quality Raw materials and processed under stringent Quality Control. Our duct heaters are composed of tubular or finned tubular heating elements that are either flanged or Slip inserted in the duct for air flowing ventilation systems and comfort heating applications. Matrusree can configure electric duct heaters exactly according to client specifications in a way they get easily adaptable solutions.
Duct heaters are heat transferring devices which are an assembly of heating elements mounted in a frame or duct. Preferably used for non-pressurized air-heating systems, there are three types of duct heaters available: open coil, tubular or finned tubular heating elements that are either flanged or inserted in the duct. If any application needs a very large capacity of heat duty, then bundle of several smaller duct heaters can be made & assembled in series. The individual elements are removable through the housing of the assembly, which eliminates the need to pull the complete heater from the ductwork. This reduces downtime costs because the heating elements can be replaced individually. Being the most easily adaptable heating solution, they are easily installed in applications requiring a wide range of temperature versus air flow combinations and offer greater reliability, energy efficiency, quicker response time and reduced infiltration from the air steam. Duct heaters can be equipped with a temperature control system and wired in various power configurations.
TECHNICAL SPECIFICATION:
| Sheath Material | Steel, Copper, Stainless Steel, INCOLOY |
| Heating Element | Tubular, Finned and Open Coil |
| Watt Density | Up to 40 W/in2 |
| Wattage | Up to 2 MW |
| Controls | SSR/ SCR/ Digitally Controlled |
| Diameter of Tube | 0.260, 0.315, 0.375, 0.430, 0.475 (inches) |
| Voltage | 120, 240, 300, 480, 600 |
| Sheath Length | 11 – 240 inches |
| Process Temperature | -29°C to 650°C |
| Wattage Tolerance | +5%, -10% |
| Resistance Tolerance | -5%, +10% |
